Transducer Type Dynamic
Frequency Response 55 Hz – 15 kHz
Polar Pattern Hypercardioid
Output Impedance 580 ohms
Sensitivity 2.2 mV / Pa @ 1k
Capsule Technology LM Type A
Off-Axis Rejection >20 dB
Maximum SPL =137 dB
Power Requirements None
Connector 3-pin XLRm
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
Materials / Finish Zinc Alloy / Black Finish
Weight 283 g / 10 oz
Length 145 mm / 5.7 in
