~Black 12" Active 2-way Ldspkr

Name: ~Black 12" Active 2-way Ldspkr
SKU: M45W

Brand: Audix

Model: M45W

UPC: 687471151129

Please log in to see your price

Dealer locator

The M45 is a miniaturized shotgun condenser microphone with a swivel-and-pivot base for convenient aiming and positioning.

Transducer Type Condenser

Frequency Response 85 Hz – 8 kHz

Polar Pattern Supercardioid

Output Impedance 150 Ohms

Sensitivety 98 mV / Pa @ 1 kHz

Signal to Noise Ratio 72dB

Maximum SPL >124 dB

Dynamic Range 100dB

Operating Voltage 18 – 52 V

Connector RJ45

LEDs Red & Green

Materials / Finish Brass & Aluminum / White

Weight 195g

About This Product

Description:

The M45 is a miniaturized shotgun condenser microphone with a swivel-and-pivot base for convenient aiming and positioning. The M45 is optimized for vocal intelligibility and offers high sensitivity, an integrated preamp, immunity from RF interference, and is easy to install in a 1-1/2” hole with no additional tools required. Mic-level signal and LED control is over an RJ45 connection. An adapter is included to convert from RJ45 to an 8-conductor pluggable terminal block. For use in Dante® networks, the optional AUDIX DN4 Enhanced Onramp for Dante | AES67 supports up to four devices and includes LED logic control. Designed, machined, assembled, and tested by Audix in Wilsonville, Oregon.

Specifications
