Transducer Type Pre-Polarized Condenser
Frequency Response 40 Hz – 20 kHz
Polar Pattern Cardioid / Omni
Output Impedance 200 ohms
Sensitivity 6 mV (C) / Pa @ 1k 8 mV (O) / Pa @ 1k
Equivalent Noise Level < 31 / 30 dB (A-Weighted)
Signal to Noise Ratio > 63 / 64 dB
Dynamic Range 99 dB / 130 dB
Maximum SPL > 130 / > 134 dB
Power Requirements 9-48 V Phantom Power
Cable / Connector Shielded 3’ (L5) terminating to a miniature 3 pin XLRf connector
Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
Materials / Finish Machined Brass / Black Finish
Weight 13 g / 0.47 oz
Length 23 mm / 0.91 in
