Name: Dual Channel FET Comp Rev D Clean Gain Discrete FET
SKU: WA76-D2

Brand: Warm Audio

Model: WA76-D2

UPC: 850031640634

Single Channel FET Comp Rev D Clean Gain Discrete FET

Single Channel FET Comp Rev A Blue Stripe Vintage FET

Dual Channel FET Comp Rev A Blue Stripe Vintage FET

Please log in to see your price

Dealer locator

Closed-Back Professional Studio Headphones For Tracking, Mixing, Monitoring, & Critical Listening.

100% Analog Discrete 2-Channel FET Compressor

Faithful Recreation Of The Vintage “Rev D” FET Compressor With Added Recording Features

VU Meter Options: Gain Reduction | +8dB Output | +4dB Output | “Off” Powers off unit

100-230v IEC Inlet Universal Power Supply

Class-A Line-Level Output Amplifiers

100% Discrete Audio Signal Path Using 600O Input Impedance Attenuator

Selectable 10kO Input Impedance To Better Match Modern Audio Interface Specifications

100% Dry-Wet Mix Control | Variable Sidechain High Pass Filter: 30 - 300Hz, 12dB/Octave

Active Bypass For Running Unit As Line Amplifier & True Bypass Option For A/B Comparisons

3 2-Channel Operating Modes: Stereo Linked | Primary:Secondary | Dual-Mono

2U 19? Rackmount Chassis

Utilizes Premium O-12 Input & 5002 Output Transformers From CineMag USA

Vintage-Spec Attack & Release: Attack = 20 µS - 800 | Release: 50 mS - 1.1 Second

“All-Buttons-In” Setting For Experimental & Hard-Limiter Tones

Frequency Response: ± 1 dB 20 Hz - 20 kHz

Balanced XLR & TRS Inputs & Outputs

Total Amplifier Gain: 53dB

Signal-To-Noise Ratio (SNR): 86dB

Total Harmonic Distortion (THD): -64dB (at -8dBu)

About This Product

Description:

The WA76-D2 accurately reproduces 2-channels of one of the fastest and most loved studio compressors of all time known for its generous headroom, ultra-fast dynamic control, and rich analog tone. Using premium and custom components like O-12 (input) and 5002 (output) transformers from CineMag, WA76-D2 achieves authentic 76 rev D style compression, known for “low noise” preamp stage with unmistakably analog character. Added modern controls to achieve parallel compression, active & true-bypass, and variable sidechain filtering flexibility make WA76-D2 an ideal choice for modern recording workflows that require vintage tone shaping. WA76-D2 recreates the legendary tone & control of the vintage 76-style compression used in studios by artists like Missy Elliott, Timbaland, Van Halen, Rick Rubin, Daft Punk, and many more.
