Audix

Special Order Microphone

Brand: Audix
Model: D4-ADX
UPC: 687471121030
Please log in to see your price
Dealer locator
With a wide frequency response of 40 Hz – 18 kHz and the ability to handle SPLs in excess of 144 dB, the D4 dynamic instrument microphone is an excellent choice for miking instruments requiring precise, low-frequency reproduction.

Transducer Type Dynamic

Frequency Response 40 Hz – 18 kHz

Polar Pattern Hypercardioid

Output Impedance 280 ohms

Sensitivity 1.4 mV / Pa @ 1k

Capsule Technology VLM Type D

Off-Axis Rejection >20 dB

Maximum SPL =144 dB

Power Requirements None

Connector 3-pin XLRm

Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector

Materials / Finish Black Hard Coat

Weight 128 g / 4.5 oz

Length 100 mm / 3.9 in

more
About This Product

Description:

With a wide frequency response of 40 Hz – 18 kHz and the ability to handle SPLs in excess of 144 dB, the D4 dynamic instrument microphone is an excellent choice for miking instruments requiring precise, low-frequency reproduction such as large rack toms, floor toms, cajon, djembe, tympani, leslie bottom, bass flute, saxophone and baritone saxophone, trombone, acoustic bass, bass cabinets, and small kick drums. The D4 is lightweight, compact, and easy to position. Used for stage, studio, and broadcast applications, the D4 dynamic instrument microphone is designed with a hypercardioid pickup pattern for isolation and feedback control. The D4 hypercardioid is also equipped with a VLM™ diaphragm for natural accurate sound reproduction.
Specifications
  • Barcodes
  • UPC
  • 687471121030
  • Package Measurements & Shipping Weights
  • Case Pack
  • Each
  • 999
  • Each
  • Cubic Feet
  • 0.0591
  • Height In Inches
  • 2.7
  • Length in Inches
  • 8.8
  • Pounds
  • 0.7
  • Width Inches
  • 4.3
