All-purpose Pencil Condenser Microphone

Name: All-purpose Pencil Condenser Microphone
SKU: F9-ADX

Brand: Audix

Model: F9-ADX

UPC: 687471141120

Please log in to see your price

Dealer locator

This f9 all-purpose pencil condenser microphone is suited for instruments requiring detailed reproduction in mid-high and extended high-end frequency ranges in live and studio applications.

Transducer Type Pre-Polarized Condenser

Frequency Response 40 Hz – 20 kHz

Polar Pattern Cardioid

Output Impedance 200 ohms

Sensitivity 8 mV / Pa @ 1k

Capsule Technology Gold Vapor Deposition

Equivalent Noise Level 25 dB (A-weighted)

Signal to Noise Ratio 69 dB

Off-Axis Rejection >24 dB

Maximum SPL =137 dB

Power Requirements 12-48 V Phantom

Dynamic Range 112 dB

Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector

Materials / Finish Zinc Alloy / Black Finish

Weight 95 g / 3.3 oz

Length 111 mm / 4.37 in

About This Product

Description:

This f9 all-purpose pencil condenser microphone is suited for instruments requiring detailed reproduction in mid-high and extended high-end frequency ranges in live and studio applications. A wide cardioid pick-up pattern paired with high sensitivity allows close, overhead, and distance miking. With its low impedance and balanced output, the f9 instrument condenser microphone has an interference-free performance. This microphone operates on phantom power of 12-48 V.
