Max. SPL @ 10 % THD : 125 dB, @ 90 Hz, half space
Max. SPL peak @ 10 % THD: 128 dB, 40 Hz - x-vver, half space
Frequency response +/-3 dB: 48 Hz – x-over
Frequency response -10 dB: 44 Hz – x-over
Power amp output bass: 1,500 W
.Power amp output column: 900 W
Amp type: Class D
LF driver: 1 x 15"
Active crossover frequency: 160 Hz
Analog inputs: 1 x XLR combo balanced
Analog thru: 1 x XLR balanced
Cardioid out: 1 x XLR balanced
Network port: Ethercon RJ45, 1x In, 1x Thru
Filter presets: 1x E 835, 2x E 835, 3x E 835, Remote
Remote software: DSP CONTROL (Windows, Mac OS)
DSP-Funktionen: Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute
Sample rate: 96 kHz
System latency: Less than 2.6 ms
Mains connector: 1 x Powercon NAC3 In, 100–240 V
Speaker outputs: 1 x E-Connect, 1x Speakon
Power consuption: 1 A / 100–240 V nominal according to EN 62368-1
Carrying handles: 2 x MultiGrip
Housing: MDF
Finish: Water-based paint, black
Front grille: 2 mm metal grille backed with black acoustic foam
Dimensions (WxHxD): 48.5 x 48.5 x 59.5 cm
Weight: 29.6 kg
