HK Audio

2400-Watt Active Subwoofer

Brand: HK Audio
Model: ELEM-115-SUB-D
UPC: 4039373023848
Please log in to see your price
Dealer locator
The 6X-500VIN "Vintage Edition" juices your 500 Series rack with a single-channel transformer-coupled mic preamp, along with a passive 2-band Pultec-style equalizer.

Max. SPL @ 10 % THD : 125 dB, @ 90 Hz, half space

Max. SPL peak @ 10 % THD: 128 dB, 40 Hz - x-vver, half space

Frequency response +/-3 dB: 48 Hz – x-over

Frequency response -10 dB: 44 Hz – x-over

Power amp output bass: 1,500 W

.Power amp output column: 900 W

Amp type: Class D

LF driver: 1 x 15"

Active crossover frequency: 160 Hz

Analog inputs: 1 x XLR combo balanced

Analog thru: 1 x XLR balanced

Cardioid out: 1 x XLR balanced

Network port: Ethercon RJ45, 1x In, 1x Thru

Filter presets: 1x E 835, 2x E 835, 3x E 835, Remote

Remote software: DSP CONTROL (Windows, Mac OS)

DSP-Funktionen: Fully parametric 10-band EQ with variable filter characteristics, High-Pass Filter, Low-Pass Filter, Polarity, Level, Delay, Limiter, Mute

Sample rate: 96 kHz

System latency: Less than 2.6 ms

Mains connector: 1 x Powercon NAC3 In, 100–240 V

Speaker outputs: 1 x E-Connect, 1x Speakon

Power consuption: 1 A / 100–240 V nominal according to EN 62368-1

Carrying handles: 2 x MultiGrip

Housing: MDF

Finish: Water-based paint, black

Front grille: 2 mm metal grille backed with black acoustic foam

Dimensions (WxHxD): 48.5 x 48.5 x 59.5 cm

Weight: 29.6 kg

more
About This Product

Description:

Compared to the subwoofers already available in the ELEMENTS family, the new ELEMENTS E 115 Sub D subwoofer delivers significantly increased bass performance. In combination with the 1500-watt power amplifier, the 15" woofer achieves considerably more sound pressure right into the low end. As a system subwoofer, it also offers a 900-watt power amplifier as a powerful drive for up to three E 835 mid/high units. High-performance 15" system subwoofer with 2,400 watts total power (1,500 watts for bass and 900 watts for up to three E 835 mid/high units). Integrated, network controllable DSP with 4 presets and Plug’n’Play Cardioid Out. Full control over all functions, EQ, limiter, delay, presets etc. HK Audio DSP CONTROL software for full compatibility with LINEAR 7, can be operated together with LINEAR 7 speakers in the same network. Subwoofer can be expanded with the LINEAR SUB 1500 A, also as a Cardioid setup. Perfect expansion for existing ELEMENTS users thanks to compatibility with E 835/435 and the EP 1/2 and EF 45 accessories. Extremely simple handling: even a large Cardioid setup with two 15" basses and three E835s can be transported in a station wagon and set up by a single person. 5-year manufacturer warranty after registration
Specifications
  • Barcodes
  • UPC
  • 4039373023848
