Audix

PS Headworn Tan

Brand: Audix
Model: VX10
UPC: 687471201008
Please log in to see your price
Dealer locator
The VX10 condenser vocal microphone was designed to set new performance standards for live sound and broadcast applications.

Transducer Type Condenser

Frequency Response 40 Hz – 20 kHz

Polar Pattern Cardioid

Output Impedance 250 ohms

Sensitivity VX10 – 24 mV / Pa @ 1k VX10LO – 4 mV / Pa @ 1k

Equivalent Noise Level 19 dB (A-weighted)

Signal to Noise Ratio 75 dB

Off Axis Rejection >20 dB

Maximum SPL =138 dB (w/ -10 pad)

Power Requirements 48-52 V

Connector 3-pin XLRm

Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector

Materials / Finish Zinc Alloy & Machined Brass / Black Finish

Weight 310 g / 10.9 oz

Length 180 mm / 7.1 in

more
About This Product

Description:

The VX10 condenser vocal microphone was designed to set new performance standards for live sound and broadcast applications. With a uniformly controlled frequency response from 40 Hz – 20 kHz, the VX10 is highly sensitive to transient response and will reproduce vocals and speech with exceptional detail and realism. The VX10 has a cardioid polar pattern which helps isolate vocals. This mic includes a 21 mm gold vapor capsule and a multi-stage internal pop filter. It is also available in a low output model (VX10LO) for greater control with loud stage volumes or extremely powerful vocalists. Aside from vocals, the VX10 cardioid condenser microphone will capture acoustic instruments such as guitars, woodwinds, brasses, percussion toys, drum overheads, hi-hats, and pianos.
Specifications
  • Barcodes
  • UPC
  • 687471201008
  • Package Measurements & Shipping Weights
  • Case Pack
  • Each
  • 999
  • Each
  • Cubic Feet
  • 0.1289
  • Height In Inches
  • 4
  • Length in Inches
  • 9.6
  • Pounds
  • 1.95
  • Width Inches
  • 5.8
