Two power supply circuits for redundancy [CG-2000 only]
Supports video reference/word clock redundancy [CG-2000 only]
Internal clock uses a high-precision OCXO (oven-controlled crystal oscillator) that is not influenced by the temperature of the environment
External input connector that supports 10MHz, allowing creation of systems with even higher precision
Jitter management circuit provides stable clock
Glitch-free relocking circuit prevents noise and skipping during clock dropouts and recovery
Numerous output connectors, including (12) word clock outputs, enabling the use in large-scale video/audio synchronization systems
Supports input and output of a variety of video signal formats, including NTSC, PAL and HD Tri-level
AES3 and AES11 signals can also be used for external master clock input sources
Analyzer function that can measure output device termination
Optimal levels can be provided to other devices by adjusting wordclock output levels
Error status can be outputted using GPO parallel output, allowing the monitoring of error occurrence
Self-calibration function using an external oscillator (Atomic/GPS 10MHz, GPS PPS)
*Use of the self-calibration function requires the use of a separate PPS-output 10MHz oscillator with a built-in GPS antenna.
Word clock performance up to 192 kHz
0.1% pull-up/down for 24F(Film) and 29.97F(NTSC), and 4% pull-up/down for 24F(Film) and 25F(PAL)
Up to (4) system settings can be saved to buttons for recall, and saved settings can be imported and exported via USB
Durable nut-coupling BNC connectors made by Amphenol
Independent circuit boards for each connector prevents contact failures due to twisting
Three-prong IEC power cable included
Panel-lock switch can be used to prevent inadvertent changes to unit operation
128x64-pixel organic EL display with a wide viewing angle
Firmware updates possible using the USB port
EIA 1U rack mount size
RoHS-compliant product
